RANGE OF PRODUCTS

  Width of radiators:

300 / 380 / 520 mm

 Raw material used:

CRCA-D grade material

( As per BIS-513D/ DIN 1623 standards)

Center distance range:

500 mm to 4000 mm.

Range of Fins:

5 No's to 36 No’s.

Distance between Fins (pitch):

40 / 45 / 50 mm.

Thickness of the steel Sheet:

1 / 1.2 mm.

Bracing straps or rods:

M.S Flats 25 x 5 mm or 10 mm Bright Rod (As per DIN 17100)

Header Pipe:

80 NB ( O.D 88.9 mm ), 2.5 / 3 / 3.5 mm Thickness

Or

100 NB ( O.D 114 mm ), 3.2 / 3.6 mm

Thickness (As per DIN 2393).

Flange Thickness :

12 mm / 18  mm Thickness (As per DIN 2393).
